Index Type

S-500-12

S-500-13.5

S-500-15

S-500-24

S-500-27

S-500-48

DC Voltage

12V

13.5V

15V

24V

27V

48V

Voltage Tolerance

±2%

±2%

±1%

±1%

±1%

±1%

Rated Current

40A

36A

32A

20A

18A

10A

Current Range

0-40A

0-36A

0-32A

0-20A

0-18A

0-10A

Ripple&Noise(Max.)

240mVp-p

240mVp-p

240mVp-p

240mVp-p

200mVp-p

300mVp-p

Line Regulation

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load Regulation

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Rated Power

480W

486W

480W

480W

486W

480W

Efficiency

84%

84%

83%

85.5%

86.5%

87%

Voltage Adjust Range

10-13.2V

12-15V

13.5-18V

20-26.4V

24-30V

41-56V

Voltage Range

88～264VAC 47-63Hz;124～370VDC

AC Current

7A/115V3.5A/230V

Inrush Current(Max.)

18A/115V36A/230V

Leakage Current

<3.5mA/240VAC

Overload Protection

105-135% TYPE：Current limitation　auto recovery

Over-voltage Protection

13.8-16.2V

15.5-18.2V

18-21V

27.6-32.4V

31-36.5V

57.6-67.2V

Over-temperature Protection

≥55℃FAN ON ≤45℃FAN OFF ≥70℃OUTPUT CUTOUT

Temp.Coefficient

±0.03%/℃(0～50℃)

Setup.Rise,Hold Time

1.5s,50ms,20ms

Vibration

10～500Hz,2G10min,/11cycle,60min,each axes

Withstand Voltage

I/P-O/P:3KVACI/P-FG:1.5KVACI/P-FG:0.5KVAC

Isolated Resistor

I/P-O/P,I/P-FG,I/P-FG:500VDC/100MΩ

　　Working Temp.Humidity

-10℃～+50℃,20%～90RH

　　Storage Temp.Humidity

-20℃～+85℃,10%～95%RH

　　Dimension

240×125×65mm

　　Weight

1.35 kg

　　Safety Standards

UL1950

　　EMC

CISPR22(EN 55022),IEC1000-4,2,3,4,5,6,8,11  IEC1000-3-2
