Female Chip-shaped Pre-insulating Terminal

Female Chip-shaped Pre-insulating Terminal



1.Cable size: 0.5~1.5mm2(A.W.G 22~16)

Max current:Imax=10A     Material:Purple Copper  Thickness:0.75mm

Type

Dimension(mm)

Color

B

L

F

H

Dφ



LBV 1.25-3

3.0

26.8

16.8

10.0

4.3

Red



LBV 1.25-4.6

4.6

26.8

16.8



2.Cable size: 1.5~2.5mm2(A.W.G 16~14)

Max current:Imax=27A     Material:Purple Copper   Thickness:0.8mm

Type

Dimension(mm)

Color

B

L

F

H

Dφ



LBV 2-3

3.0

26.8

16.8

10.0

4.9

Blue



LBV 2-4.6

4.6

26.8

16.8



3.Cable size: 4~6mm2(A.W.G 12~10)

Max current:Imax=48A    Material:Purple Copper   Thickness:1.0mm

Type

Dimension(mm)

Color

B

L

F

H

Dφ



LBV 5.5-3

3.0

29.3

16.8

13.0

6.7

Yellow



LBV 5.5-4.6

4.6

29.3

16.8
